Multi-Function Twin Drum Winch - Ideal for Towing, Dredging & Cable Lay Operations
The Double Drum Winch is an industrial-grade lifting and pulling system engineered for complex operations requiring simultaneous load handling. Featuring two independent 10HP motors, this winch delivers 15,000lb (6,804kg) combined capacity with precision control over both drums. The dual braking system ensures safe load management, while the modular design allows customizable configurations for specialized applications.
Key Innovations:
✔ Smart Load Balancing - Automatic weight distribution between drums (±2% accuracy)
✔ All-Terrain Mobility - Integrated trailer hitch and 360° rotating base
✔ Advanced Safety - Dual emergency stops + overload sensors on each drum
✔ Weatherproof Construction - Marine-grade aluminum housing (IP68 rating)
Performance Advantages:
Technical Specifications:
Critical Applications:
| Item No. | 09151 | 09152 | 09162 | |
| Model | JJCS-50J | JJQS-50J | JJCS-50T | |
| Engine | Model | KF186A Diesel Engine | Honda 390 Gasoline Engine | S195G Diesel Engine |
| Power(KW) | 6.3 | 6.6 | 9 | |
| Speed(RPM) | 2600 | 3600 | 2000 | |
| Pull force (KN)/ Speed (M/MIN) | Slow | 50*6.0,30/10 | 50/6.0,30/10 | 50/3.1,40/9.6 |
| Moderate | / | / | 45/7.1,17/22.3 | |
| Fast | 13/23,10/30 | 13/23,10/30 | 33/11.3,10/35.6 | |
| Reverse | -/5,-/17 | -/5,-/17 | -/7.35 | |
| Drum bottom of groove diameter | Φ230 | Φ230 | Φ300 | |
| outline size(MM) | 1280*770*600 | 1280*770*600 | 2440*1300*1140 | |
| Weight(KG) | 280 | 270 | 700 | |
